Fully Automatic Pet Preform Injection Moulding Machine

Fully Automatic Pet Preform Injection Moulding Machine Specification

Type
Plastic Injection Molding Machine

Style
Horizontal

Computerized
Yes

Automatic
Yes

Feature
High Efficiency, ECO Friendly, Low Noise, Lower Energy Consumption, Smooth Running, High Speed Response, High Performance

Color
BLUE

Warranty
1 year

Fully Automatic Pet Preform Injection Moulding Machine Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash Advance (CA), Cash in Advance (CID)

Main Domestic Market
All India

About Fully Automatic Pet Preform Injection Moulding Machine

With the assistance of our team of professionals, we are engaged in offering a wide range of Injection Blow Moulding Machines. Manufactured using supreme class components and latest technology, these machines are designed and manufactured as per the set quality standards. Tested on different quality parameters, these machines are acknowledged for high performance, rugged construction, easy installation, precision engineering and a long service life. Our precious clients can avail these Injection Blow Moulding Machines from us at market leading prices.

Features:

Consistent performance
Easy operation
Less maintenance require
Longer functional life

Specifications:

MODEL	NEC-250
	A	B	C
INJECTION UNIT
Screw Diameter mm	50	55	60
Screw Ratio l/d	24	22	20.3
Shot Size cm³	592	704	826
Injection Weight(ps) gms	539	641	752
Injection Pressure mpa	202.3	170	144.9
Screw Speed r.p.m	220
CLAMPING UNIT
Clamp Tonnage kn	2600
Toggle Stroke mm	540
Tie Bar Diameter mm	95
Space Between Tie Bars mm	570*570
Max.mold Height mm	600
Min.mold Height mm	200
Ejector Stroke mm	150
Ejector Tonnage kn	70
Ejector Number	5
OTHERS
Max. pump Pressure Mpa	16
Pump Motor Power / Servo kw	22.5/20
Heater Power kw	19
Machine Dimension (LWX) m	6.21.52.2
Machine Weight T	8.3
