Our Products

Injection Moulding Machine

Fully Automatic Plastic Injection Moulding Machine

Fully Automatic Plastic Injection Moulding Machine Specification

Product Type
injection moulding machine

General Use
plastic

Material
Other

Type
Injection Blow Molding, Preform Injection, Plastic Injection Molding Machine

Style
Horizontal

Capacity
50 to 650 Kg/hr

Weight (kg)
3.50 Tonne

Computerized
Yes

Automatic
Yes

Control System
PLC Control

Clamping Force
50-650 Kilonewton (kN)

Mold Thickness
Vary Square Feet

Ejector Stroke
Vary Millimeter (mm)

Ejector Force
Vary Meganewton (MN)

Injection Rate
Vary sq m/s

Injection Pressure
Vary kgf/cm2

Screw Diameter
Vary Millimeter (mm)

Screw Torque
Vary gf-cm

Tie Bar Size
Vary

Screw Stroke
Vary

Opening Stroke
Vary Millimeter (mm)

Heating Power
Vary Kilowatt (kW)

Fuel Tank Capacity
Vary Kilogram(Kg)

Pump Pressure
Vary Pa

Voltage
440 Volt (v)

Dimension (L*W*H)
Vary Millimeter (mm)

Feature
ECO Friendly, High Performance, Low Noise, Lower Energy Consumption, High Efficiency, High Speed Response, Smooth Running

Color
Black blue

Warranty
1 year

Fully Automatic Plastic Injection Moulding Machine Trade Information

Minimum Order Quantity
1 Unit

FOB Port
Delhi

Supply Ability
4 Units Per Week

Delivery Time
1 Week

Sample Policy
Contact us for information regarding our sample policy

Main Domestic Market
All India

About Fully Automatic Plastic Injection Moulding Machine

Plastic Injection Moulding Machine

We are the prominent manufacturer and supplier of a Plastic Injection Moulding Machine. Our offered machine is designed and manufactured by our adroit professionals using supreme class components as per the set industry norms. Highly acknowledged for its high performance, sturdy construction, durable finish standards and a long service life, this machine is extensively demanded in the market. This Plastic Injection Moulding Machine is available in various technical specifications that can be custom designed as per the clients given specifications.

Features:

Strong & anti-corrosive structure
Easy to operate
Ergonomic design
Less energy consumption

Specifications:

MODEL	NEC-130
	A	B	C
INJECTION UNIT
Screw Diameter mm	38	42	45
Screw Ratio l/d	24	22	20.5
Shot Size cm³	226	277	318
Injection Weight(ps) gms	206	252	289
Injection Pressure mpa	208	171	149
Screw Speed r.p.m	185
CLAMPING UNIT
Clamp Tonnage kn	1300
Toggle Stroke mm	380
Tie Bar Diameter mm	70
Space Between Tie Bars mm	420*420
Max.mold Height mm	450
Min.mold Height mm	160
Ejector Stroke mm	140
Ejector Tonnage kn	50
Ejector Number	5
OTHERS
Max. pump Pressure Mpa	16
Pump Motor Power / Servo kw	10/15
Heater Power kw	8
Machine Dimension (LWX) m	4.61.52.1
Machine Weight T	4
